Product Introduction

The Flange V-Port Stainless Steel Ball Valve is designed for precise flow control in demanding industrial applications. Its V-shaped ball design delivers stable, repeatable flow characteristics, combining excellent throttling precision with bubble-tight shutoff. The valve body has its own...

The Flange V-Port Stainless Steel Ball Valve is designed for precise flow control in demanding industrial applications. Its V-shaped ball design delivers stable, repeatable flow characteristics, combining excellent throttling precision with bubble-tight shutoff. The valve body has its own flange, which is connected to the pipe flange one-to-one by bolts, and has a strong structure, high pressure resistance, durability and smooth operation, and smooth operation across a wide range of process conditions.

To meet diverse control needs, YEKE provides you with comprehensive drive options: standard handles for manual operation, turbine heads for large-caliber, labor-saving adjustment, as well as precise electric actuators and efficient pneumatic actuators for automated control.

Key Features
Precision Flow Control:
V-port design enables fine throttling with linear or equal percentage characteristics.
Durable Stainless Steel Construction:
CF8M / SS316 body provides superior corrosion and wear resistance.
Tight Shutoff Performance:
Advanced seat design ensures zero leakage even under high pressure or frequent cycling.
Smooth & Stable Operation:
Low-torque design ensures consistent actuation for manual or automated systems.
Easy installation:
Directly align the valve flange with the pipe flange and connect them with bolts. When disassembling, only one side needs to be loosened, which is convenient for maintenance.


Typical Applications
Process control in chemical and petrochemical industries
Water treatment and wastewater plants
Pulp & paper and power generation systems
Food & beverage and pharmaceutical production lines

Advantages
Precise flow regulation with V-port design
Reliable sealing under demanding conditions
corrosion-resistant, and long service life
Compatible with electric or pneumatic actuators
Low maintenance and cost-effective performance
